Connecting to SQL Server (SQL Client) in Data Sync

The Microsoft SQL Server (SQLClient) is based on the System.Data.SqlClient library and can be used to connect to a Microsoft SQL Server and Azure SQL Database instance.

SELECT, INSERT, UPDATE and DELETE SQL Statements are automatically calculated from the Data Schema. Only those columns in the Schema Map are affected the Key(s) columns define the WHERE condition for UPDATE and DELETE actions.

In Incremental Mode the IN clause is used to return matching records based on the Key selection in groups of 500 across multiple CPU threads. It is advised that the Key column is an Indexed SQL Column.

Connect​

To connect to your SQL Database using SQLClient, in the connection window expand the SQL Database folder and select Microsoft SQL Server (SQLClient).

Connect to SQL Server

Enter in the server name, any required credentials and determine if the connection should be encrypted and the Server Certificate trusted. Then click Connect & Create Library Connection to save the connection to the Database you select in the next window.

We have a few details below about the Server Name and Authentication to help you connect to your SQl Server.

Server Name​

Enter in the network name of your SQL Server, this can also be a SQL Instance e.g. SQL01\SQLEXPRESS . Note that the SQlClient provider also supports names in the format tcp:SQL01\SQLEXPRESS, 1433 specifying the TCP protocol and port number.

Authentication​

You then need to enter the credentials to enable the connection to the SQL Server. There a few options to choose from: Windows Authentication, SQL Authentication, Azure AD Password, Azure AD Integrated.

Selecting Windows Authentication will use the current process (user).
Selecting SQL Authentication will allow you to define a SQL account to connect.
Choosing either Azure Active Directory Password or Integrated will allow you to use Azure AD credentials to connect.

info

Note that SQL Azure requires that the username includes the server name as a postfix i.e. username@servername

Authentication Options

Additional Connection Properties​

If you need to supply additional connection properties outside of the default you can add these by clicking onto the Additional Connection Properties tab.

Scroll through the list and add any additional properties required.

Once you are done click Connect & Create Library Connection to save the connection to the connection library.

Additional Connection Properties

Data source​

After connecting a window will open where you need to select the database to connect to within your SQL Server, and a SQL object to connect to (table or view). Data Sync will provide a Tree View of your SQL Server Databases, Tables and Views, expand this to find the object to connect to.

Connect to SQL Server Table

You can optionally enter a SQL Query via the SQL tab to select the data you want to work with. Specifying a SQL Query will make the data source read-only since Data Sync cannot work out how to update the data source from a user defined query.

Connect to SQL Server Query

If you previously clicked Connect & Create Library Connection then a window will appear where you can enter a name for the connection. This will load into the Connection Library window and you can access all of the SQL objects found within that database. This means you only need to configure and save the connection once as you can re-use it in future projects as needed.

Properties​

CommandTimeout​

The SQL Command timeout in seconds.

ConnectionString​

The SQL Connection String that connects to your database.

SourceTable​

The TABLE or VIEW that the Data source is connected to.

Command​

A user defined SQL Query to use instead of SourceTable setting this property overrides SourceTable and makes the Data source read-only.

Data Sync wraps your command text so it appears as an inner query SELECT * FROM (<SQL_QUERY>) T1 to support schema discovery and CommandOrderBy property.

Stored Procedures​

To call a Stored Procedure use the EXEC keyword i.e. EXEC spGetAllUsers. The EXEC keyword tells Data Sync to treat this query as a Stored Procedure.

CommandOrderBy​

Appends an ORDER BY clause to the Query.

CommandWhere​

Appends an WHERE clause to the Query, only when using SourceTable if you have a user defined Query in Command this value is ignored.

CommandBatchSize​

Specifies the number of commands to send to SQL Server in one SQL statement. SQL Server supports a maximum number of parameters of 2000 so this value must be less than COLUMNS*BATCH.

Transaction​

Specifies the number of commands per SQL Transaction.

info

Transaction > 0 will create a new Transaction on the connection.

BlobColumn​

Defines a column that is a Binary data column where Data Sync uses a separate channel to SELECT and UPDATE this value. This prevents loading these large blob values on the read operation.

This is used with providers that support File based synchronisation operations such as

  • FileSystem
  • SharePoint Document Library
  • Azure Blob Storage
  • Amazon S3 Storage
  • SQL Server

BlobName​

Defines a column that returns the name of the Blob i.e. FileName when used with SharePoint.

Project Automation​

The SQL Server provider also exposes helper functions that can be called from Project Automation to update the Data source ExecuteScalar, ExecuteNonQuery and UpdateSourceRow.

caution

Using these methods on the Target connection with a Transaction > 0 will cause a DeadLock since a SQL Transaction is in place.

ExecuteScalar​

Method ExecuteScalar creates a SQL Command from the supplied SQL and Parameters values and calls ExecuteScalar against the database.

int ExecuteScalar(string sql, params object[] parameters)

ExecuteNonQuery​

Method ExecuteNonQuery creates a SQL Command from the supplied SQL and Parameters values and calls ExecuteNonQuery against the database.

int ExecuteNonQuery(string sql, params object[] parameters)

UpdateSourceRow​

Method UpdateSourceRow creates a SQL Command to update a single column in the Data source using the key from the DataCompareItem

bool UpdateSourceRow(string column, object value, DataCompareItemInvariant item)

Used to update the source row from project automation, for example setting a Sync flag once a record has been synchronised.

For example calling this method in the AfterUpdateItem item event to mark a record in the source as synchronised.

public override void AfterUpdateItem(object sender, DataCompareItemInvariant item, object identity)
{
    DataSourceA.UpdateSourceRow("Sync", true, item);
}

Troubleshooting​

If you get the error The certificate chain was issued by an authority that is not trusted when you are trying to connect, then you need to ensure that you select the Trusted checkbox in the connection window.
